Multi Turn Wave Springs Anodized / Sandblasting With OD22mm 25mm 28mm

Name: Multi Turn Wave Springs Anodized Sandblasting With OD22mm 25mm 28mm
Brand: lisprings
Price: 1 USD

Brand Name : lisprings

Model Number : multiturn wave springs

Certification : ISO9001 TS16949

Place of Origin : CHINA

MOQ : 1

Price : Negotiable

Supply Ability : 10000000

Delivery Time : 7 work days

Packaging Details : Bulk packaged or Customize

Name : multiturn wave springs

Size : 5mm-1000mm

Tooling Charge : Free

Used For : Bearing

Material : Carbon steel or Stainless Steel

Stock : More than 2000 Types

Contact Now

Anodized / Sand Blasting OD22mm 25mm 28mm Multiturn Wave Springs

Surface Finish

1, Coating :nickel , zinc,chrome,Dacromet,teflon,silver ,gold etc.

2, Anodized : any color , can according the Panton card .

3, Sand blast,Powder coating

4, Painting

5, Laser marking,printing .

multiturn wave springs

Reducing spring housing by 50%

Waves per turn are offset by a half pitch

Total force is equivalent to one turn, whereas deflection is multiplied by the number of turns

Spring rate of wave springs decreases proportionnaly to the number of turns

Upper and Lower turns can be wavy or flat. Shim ends geometry avoids the use of support rings and provide a 360° contact surface.

In comparison with helical compression springs, Borrelly Ondufil™ offers space savings. For identical force and deflection, Borrelly wave spring enable to reduce overall housing from 50 to 75%

Borrelly Ondufil™ multiturn wave springs are available in both carbon and stainless steel.

Multi Turn Wave Springs Anodized / Sandblasting With OD22mm 25mm 28mm
